Laminate Bulker


SphereCel core materials are made of non woven textiles that are volumized with thermoplastic microspheres. There are different types in 1.2 – 12 mm thickness that are commonly used in open and closed mold processes. SphereCel products are suitable for making fiber reinforced components from 4-30 mm thickness; both flat or of complex geometry. Using SphereCel means weight savings of up to 40-60% compared to solid fiberglass laminates with comparable mechanical properties.




SphereCel PE

Polyester based laminate bulker 1-2-3-4-5 mm thickness

for sandwich laminates of any shape

  • easy of use
  • stretchable in all directions

Download
product data sheet
PDS SphereCel PE.pdf
Adobe Acrobat Dokument 586.8 KB

SphereCel GF

Fiberglass based laminate bulker 1-2-3-4-5 mm thickness



for flat and two-dimensional sandwich laminates of

outstanding surface quality

  • very fast resin absorption
  • jointless overlapping
  • excellent bonding with covering fiberglass layers

Download
product data sheet
PDS SphereCel GF.pdf
Adobe Acrobat Dokument 527.9 KB

SphereCel SBF

Stitch bonded fiberglass laminate bulker, 6-8-10-12 mm thickness

for homogenous laminates with high impact strength



  •  very fast resin absorption
  •  jointless overlapping
  •  low shrinkage due to low resin consumption

Download
product data sheet
PDS SphereCel SBF.pdf
Adobe Acrobat Dokument 288.4 KB

SphereCel SBF Type CM

Stitch bonded fiberglass laminate bulker with flow medium,

available in 6-8-10 mm thickness



for homogenous laminates with high impact strength

  • for closed mold process
  • even resin distribution throughout the product
  • low resin consumption

Download
product data sheet
PDS SphereCel SBF-CM.pdf
Adobe Acrobat Dokument 709.2 KB

SphereCel PrintBlock

Fiberglass based print blocker 1.3-2 mm thickness



for laminates with excellent surface cosmetics

  • print blocker
  • very fast resin absorption
  • invisible overlapping

Download
product data sheet
PDS SphereCel PrintBlock.pdf
Adobe Acrobat Dokument 372.9 KB

SphereCel HX Type CM

Honeycomb patterned laminate bulker 1.5-2-3 mm thickness



for thin laminates of any shape

  • for closed mould process
  • low resin consumption
  • even thickness

Download
product data sheet
PDS SphereCel HX-CM.pdf
Adobe Acrobat Dokument 515.3 KB

SphereCel HX Type OM

Honeycomb patterned laminate bulker 1.5-2-3 mm thickness



for thin laminates of any shape

  • low resin consumption
  • appealing design

Download
product data sheet
PDS SphereCel HX.pdf
Adobe Acrobat Dokument 515.8 KB
